250W Ultra Thin Linear LED Driver - 24V, 10.4A, IP67

Warranty: 5-Year

Size: 360*36*21.5mm

IP Rating: IP67

Product Weight (kg): 590g

Brand: Smart Lighting Industries

Model Number: YSD-250WUF-24

Output Power: 250W

Input Voltage: 170-264VAC

Output Current: 10.4A

Certification: CE ROHS

Protections: Short Circuit Overtemp. Overload Overvolt

Application: LED Lighting

Efficiency: 93.5%

When space is tight but performance can’t be compromised, this ultra-thin 250W LED driver offers a solid balance between compact design and high efficiency. At just 32mm wide and fully IP67-rated, it fits neatly into small enclosures or tight channels—ideal for clean installs where a bulky driver just won’t work.

It runs on a wide input voltage range (110–277V), making it suitable for both residential and commercial use across global markets. You’re getting active power factor correction, total harmonic distortion under 5%, and a power factor above 0.96. Efficiency clocks in at over 93%, which places it comfortably in the “energy-conscious” category.

We’ve integrated full protection circuitry—short circuit, over-voltage, overload, and thermal shutdown—so you’re covered on safety. It’s fully insulated in a plastic housing with no earth connection required, which helps speed up installs.

We typically recommend this model for LED strip lighting, signage, architectural projects, and slimline LED panels. It’s also EMC certified and meets ERP and EN61347 standards, which gives extra peace of mind if you're working in regulated environments.

Key Features:

• Ultra-thin linear body – just 32mm wide, 360mm long

• 24V constant voltage output, 10.4A max load, 250W total

• High efficiency (93.5%), PF > 0.96, THD ≤ 5%

• IP67 waterproof rating – suitable for outdoor or damp environments

• Built-in protections: short circuit, overload, over-voltage, over-temperature

• Fully insulated plastic casing, no earth wire required

• CE, ROHS compliant – ERP & EN61347 standards

• 5-year warranty from Smart Lighting Industries

Whether you’re designing a discreet lighting system for a client or just need a slim, reliable driver for tight installs—we’re happy to advise on compatibility and performance. Let us know the strip you’re powering, and we’ll double-check current loads and spacing for you.
